The following are two possible causes from the Levelegs troubleshooting guide. Hope this helps.
False RET (full retraction) Error Mode a. For extensions greater than 20 seconds, if the retraction time for any leveler is less than the extension time (indicating premature clutching prior to full retraction), the following occurs: 1. Human anatomy physiology lab manual. Warning alarm will sound.
Power is removed from the control box disabling normal operations. (This is done to encourage operator to do a visual inspection of levelers prior to further leveling operations.) 3.
The red and green LED’s for the particular leveler will blink on and off to indicate the system is in an error mode. To proceed, the following is required: 1. Turn system on. This will shut the warning alarm off.
Atwood Levelegs Replacement
Visually inspect the leveler. If it is required, activate levelers to correct problem. Simultaneously press the EXTEND or RETRACT mode switch along with the adjacent two (2) leveler switches common to the lit LED’s. In error mode, any leveler can be activated in this manner. Complete an ALL RETRACT operation and system is now out of error mode and ready for normal operations. No Current Error Mode a. During any operation if no current is detected from leveler after leveler is activated, the following occurs: 1.
Warning alarm will sound. Power is removed from the control box disabling normal operations. The red and green LED’s for that leveler will blink on and off to indicate the system is in an error mode. To proceed, the following is required: 1.
Turn system on. This will shut the warning alarm off.
Supply power to the leveler. Complete an ALL RETRACT operation and system is now out of error mode and ready for normal operations. In the event retraction of the levelers is required without rectifying the problem, individual levelers can be retracted by simultaneously pressing the retract mode switch along with the adjacent two (2) leveler switches common to the leveler requiring retraction. Thanks for you help, I did what you said it's seems like the front driver leg won't respond when I press retract or extend and front driver it does nothing, when I press extend or retratct and the other three they work. I still have the blinking red and green on the front driver leg and all legs are up at this time when I do a retract all I do see all four legs blinking red and hear the noise of them retracting fully but can't get rid of this warning on the front driver leg and cannot retract or extend it when I press the buttons I dont hear any noise or anything, can you help me.Thanks Tony.
